Other shops send us
their fixtures.
Fixtures, tooling, and the awkward single part.
When a job needs workholding nobody wants to design, or a replacement component that has to exist by Thursday, it lands here. We machine it, inspect every one by hand, and keep the fixture afterwards so the next batch sets up the way the first one did.
Minimum order one part · Shop opens 6 AM · Quotes next business day
Why workholding gets sent out
Machine shops call us. When a job needs workholding they have not got time to design, or a fixture plate for a run that is already late, it goes out — and it goes to a shop that builds its own. That is what this one does.
The same is true of tooling, test stands, inspection fixtures, and the single replacement component holding up a build. Low quantity, awkward geometry, needed sooner than is comfortable.
Workholding, tooling and hardware
- Fixtures located on the datums your print works from
- Dowel pins and bushings so a setup repeats rather than gets re-found
- Soft and sacrificial jaws cut to the part
- Workholding for thin walls and castings that move under normal clamping
- One-off replacement parts for equipment already in service
- Brackets, housings, spacers, adapters and mounting plates
- Test stands, inspection fixtures and ground support hardware
- Short-run production once the fixture exists
Fixtures are designed and cut here rather than outsourced, and they stay here afterwards, so a repeat order does not pay to solve the same locating problem twice.
Most of this work we cannot show you
Defense projects
Completed under non-disclosure. We can tell you how the work is done, not who it was for.
Medical device work
Also under NDA. In both sectors that restriction comes with the territory, and it is a reasonable price for the work.
We sign yours as well
NDAs are routine here. If you would rather have one in place before we look at a drawing, send it over first.
Prints, datums and finishes
The hard part is rarely the cut. It is holding a thin wall, a casting, or a part with features on five faces steady enough that it still measures right after it comes out of the fixture — and reading a print that may be thirty years old and have no model behind it.
- ±0.0001″ where the print calls for it, on the features that matter
- GD&T worked as drawn — datum structures, true position, flatness and perpendicularity
- Anodizing, plating, passivation and heat treatment through qualified vendors
- Obsolete prints and no-CAD parts measured and re-drawn before cutting
- Certificates of Conformance and material certifications on request
Materials
Aluminum 6061 and 7075 for fixtures, brackets and plates. Carbon steels and mold steels where workholding has to survive repeated clamping. Stainless 303, 304, 316, 420, 440 and 17-4 PH. Titanium. Brass, bronze and copper. Delrin, PEEK, UHMW and PTFE.
What we will ask you
Five questions, and the answers usually change the price more than the material does. If you already know them, the quote comes back faster.
- What is the part located on now, and what is moving that should not be?
- Which datums does the print work from, and which faces must be cut in one setup?
- Is this a one-off or will it come back? Either way the fixture stays here
- Does it need anodizing, plating or heat treatment afterwards?
- Is there a model, a paper print, or only the part itself?
If you are not sure
Send it anyway. A five-minute call with the machinist who would cut the part is worth more than a form, and it is usually enough to tell you whether this is the right shop for the job.
Common questions
Do you really work for other machine shops?
Yes. Fixtures and tooling for other shops’ jobs are regular work here. If you run a shop and a job needs workholding you have not got the hours to design, that is a normal call to make.
Can you build a fixture from just the part, with no drawing?
Yes. Bring the part. Measuring an existing component and working from that is routine — it is the same process as any reverse engineering job.
Do you keep the fixture for repeat orders?
Yes, and at no extra charge. The first batch carries the fixture cost. After that it sits on the shelf here, so the second order sets up the same way and does not pay for it again.
How do you handle programs with export-control or certification requirements?
We work inside your approved-supplier process, the same way we manage outside finishing vendors on a single order. Tell us what the program requires and we will tell you exactly where we fit and what would need a certified partner alongside us.
Will you sign an NDA?
Yes, and we would rather sign one first than have you send a drawing you are uneasy about. A good deal of the work here is covered by them.
What is the minimum order?
One part. That is not a concession for prototypes, it is how the shop is set up.
How quickly can you turn something around?
Quotes come back the next business day and the shop opens at 6 AM. Lead time depends on the part and on the fixture, if one is needed — ask, and you will get a real date rather than an optimistic one.
The print is from the 1980s and there is no CAD model. Is that a problem?
No, that is normal here. A paper print gets read as drawn, and where dimensions are missing or the part has been revised in service, we measure the existing component and work from that. Reverse engineering an obsolete part is regular work, not an exception.
Can you handle the finishing a print calls for?
Anodizing, plating, passivation, heat treatment, bead blasting and laser marking are coordinated through qualified outside vendors on your order, and parts come back here for inspection before they ship. Send us the finish callout on the print and we will tell you straight whether it is one of ours or one you should source yourself.
What about DFARS specialty-metals or domestic-melt requirements?
Raise it with us at quote stage. If your contract carries a domestic-melt or specialty-metals clause, that changes where material is bought and what documentation has to come with it, and it is much easier to source correctly at the start than to substitute later.
Send us the part, or the problem
A drawing, a model, or the component itself. Quotes come back the next business day, the minimum order is one part, and you will be talking to the machinist who cuts it.
